5 things You Should Know About the IEC 15118, V2G Communication Protocol

August 9, 2021
IEC 15118, V2G communication protocol|OCPP 2.0 V2G communication

Vehicle-to-grid (V2G) technology is a means to a greater end for the world of sustainable energy. Even though V2G is not yet prevalent, the structures necessary for communication between grids and electric vehicles have already started growing with advanced technology. It is essential to note that communication protocols that serve as guidelines in their various applications have to be flexible enough to accommodate change constantly.Communication protocols guide the interactions between two digitally connected entities. In this case, electric vehicles and grids are the entities. Without standards, there is always a gap and disorderliness. Such chaos is not needed in the exchange of data and the facilitation of communication in the application of V2G (Vehicle-to-grid) technology. The IEC 15118 protocol steps in to solve this problem.V2G technology can only be implemented swiftly and much more if the points of interaction between the two elements, the vehicle, and the grid, recognize each other. You would agree with me that adaptability makes any product or technology, like the advent of electric vehicle usage, more feasible and desirable. The IEC 15118 protocol is one of the other communication protocols but paves the way for a smooth transition in vehicle-grid integration.

The Focus of V2G Communication Protocols

Many concerns come up when it comes to any kind of data exchange. There is a need for the details (like the specifications & unique identity) of a vehicle to be communicated in V2G. Asides from the fact that details may easily be tracked and need a high level of security, the flexibility of the interactions between EVs, charging systems, and grids are highly required for V2G to thrive.[caption id="attachment_8468" align="aligncenter" width="940"]

EV charging

Image by Reinhard Thrainer from Pixabay[/caption]The IEC 15118 started in 2009 for the Vehicle-to-grid Communication Interface to promote autonomous usage. Interestingly, this protocol is still under development, yet it already gives a platform that allows for a broader scope. As V2G communication is needed to be in place for automatic billing and access to the internet, the IEC 15118 protocol gives a form of global compatibility that applies just as well.

IEC 15118 Protocol: What you should know

Of the two main kinds of community protocols (the front-end protocol and the back-end protocol), I would spotlight the IEC 15118 protocol (which is a front-end protocol. That is as a result of its relevance in V2G technology and its application. Also known as the ISO 15118 protocol, it is one of the International Electrotechnical Commission (IEC) standards for electric vehicles (including trucks). It has some interesting sides to it, as I would explain below.

1. More Advanced Communication with IEC 15118

Compared to a similar protocol, like the IEC 61851, the IEC 15118 communication protocol is more advanced. For example, ISO 15118 gives the requirements for charging load management, billing and metering. It thus promotes bi-directional digital communication, which is the basis for V2G communication.IEC 61851 can only do basic signalling, like indicating readiness for charging and connection status. However, IEC 15118 is applicable for high-level communication, which is an advancement. This places it at the core of EV charging and even V2G interactions. This way, there is better communication and information transfer between the Electric Vehicle and the Electric Vehicle Supply Equipment (EVSE).

2. Versatile Application of IEC 15118 to Wired and Wireless Charging

In its implementation for charging electric vehicles, you can apply IEC 15118 to both wired (AC and DC) and wireless charging. Since V2G applies to various kinds of electric vehicles, this protocol suits it appropriately.

electric vehicle charging

With the current update on part 8 of the IEC 15118 protocol, you would notice an improvement that would allow for wireless connection. Part 8, which is the Physical layer and data link layer requirements for wireless communication, informs the protocol's versatility.

3. Security via Digital Certification in IEC 1158

The communication between vehicles and grids (via V2G) with the IEC 15118 protocol is more secure. This is a result of the use of digital certificates. In addition, public key infrastructures issue and manage digital certificates. These certificates link people, systems, and keys.Like passcodes (but more complex), encrypted data is used in IEC 15118 to keep information safe. This way, the limit of insecurities in V2G communication is eliminated. Even digital signatures can be created and used as and when due. If, at any time, for any reason, a digital certificate is no longer trusted, the public key can be reversed. Also, these security features have time limits and make it harder to cheat on the system.

4. Automated Authorization

Using IEC 15118, there is no need to do any other thing at the point of shedding excess power from an electric vehicle to the grid asides from doing the necessary plugging. The automated system allows the system to authenticate the identity of the two sides in communication. It uses different authentication schemes like the Plug and Charge technology, enabling the vehicle to authenticate and identify itself on behalf of the driver.The use of RFIDs (Radio Frequency Identification) can be aptly applied in the use of IEC 15118 as a means of external identification. Low power radio waves are used in this application to identify the vehicle and automatically carry out authentication.

5. Standard Nature of the IEC 15118 Protocol

ISO/IEC 15118 is a protocol that forms part of the Combined Charging System (CCS) - a group of standards for hardware and software in charging systems. The CCS agrees to use this to enhance charging that can be operated with various specifications.The International Organization for Standardization (ISO) also recognizes the IEC 15118 protocol for V2G communication. Being an international body made of different national standards organizations that set standards, the ISO is globally recognized.

smart grid

With Hive Power's FLEXO, anywhere V2G would be implemented, charging and discharging can be coordinated easily. This is done by maximizing devices that can be remotely controlled under this module. The smart charging FLEXO app also provides a means of improving the accuracy of energy data and enhancing smart grids.Generally, the interoperability and openness of IEC 15118 make it fit in as a V2G communication protocol well. Yet, it is not at the level it should be in the market. Moreover, due to the nature of the V2G technology as one which is still under development, the entire structure needs to keep improving to aid more advanced communication between the digitally communicating elements.

Book a slot with our team to understand how Hive Power FLEXO solutions can power your smart charging and V2X projects.
